TPM 409 stretch wrapping machine

It performs the winding process by rotating the load placed on the table. The pre-tensioning unit has mechanical pre-tensioning technology. It stretches your stretch film from 100% to 75% and does a manual adjustable pre-stretch. It stretches the stretch by applying force to the load.

MACHINE FEATURES

Tower Height: 270 Cm (240 Cm Net Winding )
Rotary table diameter: 165 Cm (because the table diameter is 165cm, the product remains in the middle of the rotary table. 80x110cm, 80x120cm, 100x120cm, 120x120cm pallets are suitable for work safety because they do not overflow from the edge)
Rotary table hair thickness: 10 mm
Turntable Load Capacity: 1800 Kg
Turntable and stretch trolley: chain driven
Electric Control System: PLC Control 7 ” touch screen
Stretch Film Pre-Tensioning System: Mechanical Tensioning
Product height control: automatic height detection (photocell )
Rotary table electronic speed controlled soft takeoff system to prevent product dispersal during takeoff
Stretch winding trolley electronic speed controlled frequent and sparse winding capability
Control with remote control
Don’t stop where it started
Machine Power 1 Kw 220 Volt
Warranty period 2 years mechanical 1 year electrical
CE certificated
Static powder coating system against rust and scratch is used in our products
After-sales service to all parts of Turkey with the assurance of TUNÇ MAKINA

OPTIONAL

Ramp
Tower Height: Upgradeable
Turntable Load Capacity: Upgradeable

Category:

Description

7 ” SMART TOUCH SCREEN

CONTROL WITH REMOTE CONTROL

STRETCH TROLLEY BOTTOM PROTECTION SYSTEM

FORKLIFT ENTRY PLACES THAT ALLOW CONVENIENT TRANSPORTATION OF THE MACHINE

RAMP TO PUT THE PRODUCT ON THE TURNTABLE WITH THE HELP OF TRANSPALET
