TOS 600 pallet stretch machine

It performs automatic winding process as a result of the load placed on the conveyor reaching and rotating the turntable to be wound. The product is suitable for automatic production lines. The pre-tensioning unit has electronic motorized pre-tensioning technology. Stretching your stretch film between 250% and 300% allows you to save up to 2.5 times of stretch film. Tension adjustment at each stage of winding can be made from the control panel.

MACHINE FEATURES

Tower Height: 270 Cm (240 Cm Net Winding )
Rotary Table Diameter: 200 Cm
Rotary table hair thickness: 10 mm
Turntable Load Capacity: 1800 Kg
Turntable and stretch trolley: chain driven
Electric Control System: PLC Control 7 ” touch screen
Stretch Film Pre-Tensioning System: Electronic Motorized Tensioning
Stretching your stretch film by 250% to 300% allows you to save up to 2.5 times of stretch film
Product height control: automatic height detection (photocell )
CE certificated
Static powder coating system against rust and scratch is used in our products
After-sales service to all parts of Turkey with the assurance of TUNÇ MAKINA

OPTIONAL
Overprint System
Tower Height: Upgradeable
Turntable Load Capacity: Upgradeable
